New 2025 Knapen Agricultural Moving Floor Trailer
360 view Click for 360 view
360 View
New 2025 Knapen Agricultural Moving Floor Trailer
New 2025 Knapen Agricultural Moving Floor Trailer
YouTube Video
Video
New 2025 Knapen Agricultural Moving Floor Trailer
New 2025 Knapen Agricultural Moving Floor Trailer
Photo 1
New 2025 Knapen Agricultural Moving Floor Trailer
New 2025 Knapen Agricultural Moving Floor Trailer
Photo 2
New 2025 Knapen Agricultural Moving Floor Trailer
New 2025 Knapen Agricultural Moving Floor Trailer
Photo 3
New 2025 Knapen Agricultural Moving Floor Trailer
New 2025 Knapen Agricultural Moving Floor Trailer
Photo 4
New 2025 Knapen Agricultural Moving Floor Trailer
New 2025 Knapen Agricultural Moving Floor Trailer
Photo 5

Agricultural Moving Floor Trailer

Year 2025 (new)
Chassis Knapen Trailers BV.
Body Knapen Trailers BV.
Volume 101 CuYds (77.2m3)
Weight 8500kgs

Full Specifications

Specifications

Chassis:

Weight 8500kgs
Type Alloy Sub-Frame
Suspension Air
Brakes 0.20" BPW Drum
ABS/EBS WABCO EBS-E
Wheels Steel
Axles 3x BPW Eco Drum
Axle 1 Lift
Axle 2 Fixed
Axle 3 Fixed

Body:

Volume 101 CuYds (77.2m3)
Door Top Hung
Floor System Cargo CF500SL-C
Floor Slats 21x 6mm Smooth
Floor Parts
Chassis Grey
Body White
Cover Net Knapen Hydraulic Net System 50:50 Split
TASCC ./
Specifications

Parts Manual


For a printable parts manual for this trailer click below


Parts Manual

Description

Knapen Krone KX770 & Krone KX650 Agricultural Moving Floor Trailer For Sale

Full Description

Description

Knapen Krone KX770 & KX650 Agricultural Moving Floor Trailer For Sale

Knapen manufacture a complete range of agricultural walking floors and moving floors aimed at the UK's agricultural sector. Knapen are owned by Krone Trailers. Krone are one of the Worlds largest constructors of agricultural trailers.

Floors have the big stability advantage over tipping trailers on road and off road. They also have weight saving and volume gain.

The purpose of this trailer is a trailer that can go on to fields with wider tyres and also be road legal as a 44 tonne HGV rig.  Therefore this can be an agricultural on field chaser plus long distance motorway bulker. So if you are carrying parsley silage, grain or sugar beet, in field silage or forestry bark, chips etc

ALL homologated for the UK.

KX 770 refers to the volume of 77 cu meter or 101 cuyds.
KX 650 refers to the volume of 65 cu meter or 86 cuyds.

Tri axle on air suspension

First axle: BPW 10 Ton Airlight II 120x15mm with 420 drum brakes LIFT AXLE INCLUDED

2nd axle: BPW 10 Ton Airlight II 120x15mm with 420 drum brakes

3rd axle: BPW 10 Ton Airlight II Self Steering Axle 120 X 17mm  10bg ET-0 with 65mm spring and welded axle pads with 420 drum brakes

Moving internal headboard automatic - retractable by remote control

Cargo floor 21 plank x 6 mm aluminium floor system

Cargo floor POWERSPEED - high speed floor with manual B control direction control

Remote control for sheet, floor, working lamps

Hydraulic door - radio remote control and with integrated rear lights

Knapen Double automatic net system or Powersheet

Knapen Agricultural Moving Floor For Sale; Knapen Agricultural Moving Floor Trailer For Sale; Knapen Moving Floor For Sale

Description

Finance Estimator


Own this Agricultural Moving Floor Trailer from £478.66 per week


Get An Estimate

Own from £478.66 per week*

Initial Payment


Finance Duration


Final Payment

Residual Value

£
Final Payment

Payments

per month
( per week)

Interest Rate

comparison rate
Flat Rate

Total Paid

(excluding initial)
interest

*this estimator is not an offer to finance

Finance

Quote


For a printable quote for this trailer click below


Get a Quote


Description

Knapen Krone KX770 & KX650 Agricultural Moving Floor Trailer For Sale

Knapen manufacture a complete range of agricultural walking floors and moving floors aimed at the UK's agricultural sector. Knapen are owned by Krone Trailers. Krone are one of the Worlds largest constructors of agricultural trailers.

Floors have the big stability advantage over tipping trailers on road and off road. They also have weight saving and volume gain.

The purpose of this trailer is a trailer that can go on to fields with wider tyres and also be road legal as a 44 tonne HGV rig.  Therefore this can be an agricultural on field chaser plus long distance motorway bulker. So if you are carrying parsley silage, grain or sugar beet, in field silage or forestry bark, chips etc

ALL homologated for the UK.

KX 770 refers to the volume of 77 cu meter or 101 cuyds.
KX 650 refers to the volume of 65 cu meter or 86 cuyds.

Tri axle on air suspension

First axle: BPW 10 Ton Airlight II 120x15mm with 420 drum brakes LIFT AXLE INCLUDED

2nd axle: BPW 10 Ton Airlight II 120x15mm with 420 drum brakes

3rd axle: BPW 10 Ton Airlight II Self Steering Axle 120 X 17mm  10bg ET-0 with 65mm spring and welded axle pads with 420 drum brakes

Moving internal headboard automatic - retractable by remote control

Cargo floor 21 plank x 6 mm aluminium floor system

Cargo floor POWERSPEED - high speed floor with manual B control direction control

Remote control for sheet, floor, working lamps

Hydraulic door - radio remote control and with integrated rear lights

Knapen Double automatic net system or Powersheet

Knapen Agricultural Moving Floor For Sale; Knapen Agricultural Moving Floor Trailer For Sale; Knapen Moving Floor For Sale
