Horizontal discharge aggregate trailer available in the UK market
40 cuyd Full Hardox Steel Body fully insulated aggregate box
Triaxle on Air with Front Lift Axle
SAF Disc
Horizontal discharge system
Insulated floor; Insulated sides; Insulated door;Hydraulic Hot Asphalt Door. Top section powers upwards, bottom section powers down. Manual control and remote control system
Automatic Rear Doors
Optional: VWS Air Weigh System With Temperature Sensors and Remote Temperature Reporting
Dawbarn Hydraulic Automatic Sheet System with Remote control
Horizontal discharge of hot product. Superior insulation to any other trailer available. Proven by Eurovia throughout Europe. Proven by Tarmac and Eurovia in the UK. Load mixes at time of discharge generating even temperature and even material size. Return loads possible as the body is full HARDOX and therefore muck away type materials can be loaded. 8 tonnes greater payload than an insulated rigid. Much simpler than a walking floor aggregate or a belt trailer. Next to zero maintenance of the box or mechanism. 20 year expected life. It is HARDOX. Have an issue? Weld it up? This will save thousands of pounds per year compared to a floor or belt in maintenance and de risks your contract as if the asphalt work dries up just put it on any aggregate, muck away or skip wastes and show the middle digit to Hanson or Tarmac if needed? Then put it back on the black top when the rates are right - try that with a belt or floor and they would be in a body bag! Every fleet needs one.
*this estimator is not an offer to finance
Stock No. | SN2211 |
---|---|
Type | Asphalt Ejector Trailer |
Chassis | Fliegl |
Body | Fliegl |
Model | 8.2 Thermo Pushout |
Year | 2025 (new) |
Documents | Parts Manual |
eCO2 | 50000kg |
---|---|
Confidence | 1 (low) |
Checked | 16/11/2022 |
Weight | 8940kgs |
---|---|
Type | Steel Straight Frame |
Suspension | Air |
Brakes | 22.50" SAF SBS Disc |
ABS/EBS | Haldex Europe SAS |
Wheels | Steel |
Weigher | VWS |
Axles | 3x SAF BI9 22S SBS |
Axle 1 | Lift |
Axle 2 | Fixed |
Axle 3 | Fixed |
Volume | 36 CuYds (27.5m3) |
---|---|
Door | Hydraulic |
Insulation | Full |
Wet Kit | Ejector |
Chassis | RAL 9010 White |
Body | RAL 9010 White |
Cover | Customer Choice Dawbarn Hydraulic Roll Over Sheet Hydroclear |
