| Year | 2024 (new) |
|---|---|
| Chassis | Knapen Trailers BV. |
| Body | Knapen Trailers BV. |
| Volume | 140 CuYds (107.0m3) |
| Weight | 8230kgs |
| Stock No. | SN1140 |
|---|---|
| Type | Biomass Moving Floor Trailer |
| Chassis | Knapen |
| Body | Knapen |
| Model | 140 Biomass 10mm Dawbarn |
| Year | 2024 (new) |
| Documents |  Parts Manual |
| eCO2 | 75000kg |
|---|---|
| Confidence | 1 (low) |
| Checked | 16/11/2024 |
| Weight | 8230kgs |
|---|---|
| Type | Steel Sub-Frame |
| Suspension | Air |
| Brakes | 22.50" SAF SBS Disc |
| ABS/EBS | WABCO EBS-E |
| Wheels | Steel |
| Axles | 3x SAF BI9 22S SBS |
| Volume | 140 CuYds (107.0m3) |
|---|---|
| Door | Barn Door 50:50 |
| Catwalk |  |
| Floor System | Cargo CF500SL-C |
| Floor Slats | 21x 10mm Smooth |
| Floor Parts | |
| Headboard | Moving |
| Chassis | Galvanised |
| Body | White RAL 9010 |
| Cover | Seawolf Blue (Grey) Dawbarn Hydraulic Roll Over Sheet Hydroclear |
140 cuyd Knapen Aluminium moving floor - 4.4 meters tall over the side (we do up to 155 cuyd by request)
Taper frame - trailer gets taller towards the back allowing product to exit more cleanly
The purpose of this trailer is to move very light fluffy bulk loads. The volume is very much to the larger end of the trailer sizing for the UK. We can move to special lengths but these remain more niche - but ask if you need one.
10 mm floor thickness as standard (our competition often try and sell the 6 mm or 8 mm)
Cargo Floor CF500 SLC with remote control
Triaxle on Air SAF axles off Road CD version
Steel wheels (options for alloys)
Steel galvanised chassis with 10 year anti-corrosion warranty
4 extra cross members at rear of trailer for forklift loading
Small triangular wear plates both sides to prevent forklift loading damage
Plastic Tool box
Air operated rear door safety lock
UK reinforced sledge plate - to assist coupling and uncoupling.
Dawbarn Automatic Roll over Sheet System
*this estimator is not an offer to finance
140 cuyd Knapen Aluminium moving floor - 4.4 meters tall over the side (we do up to 155 cuyd by request)
Taper frame - trailer gets taller towards the back allowing product to exit more cleanly
The purpose of this trailer is to move very light fluffy bulk loads. The volume is very much to the larger end of the trailer sizing for the UK. We can move to special lengths but these remain more niche - but ask if you need one.
10 mm floor thickness as standard (our competition often try and sell the 6 mm or 8 mm)
Cargo Floor CF500 SLC with remote control
Triaxle on Air SAF axles off Road CD version
Steel wheels (options for alloys)
Steel galvanised chassis with 10 year anti-corrosion warranty
4 extra cross members at rear of trailer for forklift loading
Small triangular wear plates both sides to prevent forklift loading damage
Plastic Tool box
Air operated rear door safety lock
UK reinforced sledge plate - to assist coupling and uncoupling.
Dawbarn Automatic Roll over Sheet System
*this estimator is not an offer to finance
