133 cuyd
Full length steel chassis
Body Opens both sides full length. There is a movable sliding post.
Internal aperture length is 12.900 m
The toprail lifts to give an extra 30 cm of under rail height. (optional extra)
Tri axle on air
BPW Axles and BPW drum brakes
21 plank x 10 mm Floor
Internal lashing rings
Knapen flat automatic sheet system
50:50 barn doors with air operated rear door safety lock
Unique wider extruded planks that are fully seam welded (many competitors reduce cost by only stitch welding - not advised in plank side construction!)
Full robot side welding, door welding and headboard welding for perfection every time
Front headboard sidewall cast alloy joiners which prevent the headboard from splitting away
Moving internal headboard
2 year paint warranty!
Wander lead remote control
Side impact bars and rear underrun bar
Toolbox
This trailer is unique in having a full aperture available for loading on both sides. So you can load long lengths from either side. So chipboard, insulation, pallets etc. Then load bulk in the other direction - wood chips, paper etc. There is not another trailer manufacturer that can do this!! More information on
https://www.knapen-trailers.eu/trailers/side-doors-exside
*this estimator is not an offer to finance
Stock No. | SN1133 |
---|---|
Type | Side Door Moving Floor |
Chassis | Knapen |
Body | Knapen |
Model | K604 Exside Pillarless |
Year | 2025 (new) |
MOT | C1234 |
Documents | Parts Manual |
eCO2 | 85000kg |
---|---|
Confidence | 1 (low) |
Checked | 16/11/2022 |
Weight | 9200kgs |
---|---|
Type | Steel Straight Frame |
Suspension | Air |
Brakes | 0.01" BPW Drum |
ABS/EBS | WABCO EBS-E |
Wheels | Steel |
Axles | 3x BPW Eco Drum |
Volume | 133 CuYds (101.7m3) |
---|---|
Door | Barn Door 50:50 |
Floor System | Cargo CF500 |
Floor Slats | 21x 10mm Smooth |
Floor Parts | 21 plank 10mm |
Headboard | Moving |
Chassis | RAL 7016 Grey |
Body | RAL 9010 White |
Cover | RAL 7016 Grey Knapen Electric Roll Over Sheet Flat |
